Helical Remedial Ties - 8mm Diameter. 50 pcs per box.

Description

• 8mm retrofit wall tie for masonry
• Replace cavity wall ties, Pin arches, tie rubble-filled walls and secure solid walls that are delaminating
• For installation use the Drive Tie Setting Tool
• Self-tapping corkscrew function induced by work-hardened helix
• Connection for mechanical masonry-Screw
• Quick, simple and cost-effective installation

Benefits

• Fire resistant, with no need for adhesives
• Water resistant
• Made from corrosion-resistant grade 304 stainless steel
• Allows for thermal and moisture movements
• Precise twist design for exceptional reliability

Installation

The SDS driver tools deliver repetitive lightweight hammer impacts to the tie end. The impacts drive the tie into the masonry, via the pilot holes. The helix shape and it's larger size causes the tie to self-rotate as it ‘corkscrews’ into the masonry.

The pilot holes for all helical ties depend on the hardness of the masonry.

The manufacturers have tested for UKCA/CE marking using 6mm holes, which are usually OK for medium strength brickwork and blockwork. If tying into hard concrete or semi engineering bricks then a 6.5mm hole may be necessary to ease installation. On the other hand, if the bricks are extremely soft or are perforated, a carefully drilled 5mm hole may be preferable to achieve maximum hold.
