Frame Cramp Wall Ties (VE7)
Frame Cramp Wall Ties (VE7)
- Sold in boxes of 200 or 250
- Designed to fix masonry to new or pre-existing structures
- Prevents sideways movement of a wall and another element (frames etc)
- See full description below for Box Qty and more info
Vista VE7 Frame Cramp Wall Ties
- The Vista VE7 Frame Cramp is a precision-manufactured lateral restraint fixing
- Designed to tie masonry walls back to existing or new structural elements, including pre-existing masonry and structural steelwork.
- It is also suitable for incorporating non-structural elements such as window and door frames.
- By restricting lateral displacement, the VE7 enhances overall wall stability and is widely used in cavity wall construction and façade applications.
- Also available in boxes of 10
Box Quantities
| Size | Box Quantity |
| 75mm - 200mm | 250 |
| 225mm - 300mm | 200 |
Application:
- Used to restrain masonry walls to steelwork, concrete, or existing masonry structures
- Commonly installed in conjunction with non-structural elements including window or door frames
- Ideal for general masonry construction where lateral restraint is required
Design:
- Traditional flat frame cramp profile, typically built into mortar joints and fixed to substrates with suitable fixings (not supplied)
- Available in a range of lengths from 75mm to 300mm to accommodate various embedment requirements
- Designed to offer simplicity of installation and effective load transfer
Material
- Manufactured from grade 304 stainless steel in accordance with BS EN 10088-1
- Provides excellent corrosion resistance in exposed or damp environments
Behaviour in Relation to Fire
- Classified as non-combustible under the UK Building Regulations, suitable for use in regulated fire-rated wall systems
Durability:
- Exhibits excellent resistance to corrosion, supporting a minimum service life of 60 years under normal environmental exposure
- Meets durability and performance expectations outlined in national standards and NHBC guidance
