Vertical (Light Duty) Restraint Straps (LDMH) - Bend at 100mm
Vertical (Light Duty) Restraint Straps (LDMH) - Bend at 100mm
Light-duty restraint straps are designed for vertical restraint applications, such as holding down wall plates to masonry.
Galvanised Steel
Other sizes/alterations are available on request
The sizes below are overall length (girth) with bend at 100mm
Light Duty Bent Restraint Strap - Bend at 100mm
Designed in accordance with The Building Regulations, BS5268 Part 3, and other building standards for vertical and horizontal restraint, these light-duty straps have been tested to BS EN845-1 to ensure quality and safety.
Multi-holed straps are supplied with 6mm holes at 25mm offset centres.
These light-duty straps offer a load-bearing capacity of 4 kN, providing reliable support for your vertical restraint applications.
To ensure secure fixing, our straps should be fixed using either 50mm long no. 12 woodscrews (using wall plugs in masonry for vertical restraint) or 75mm x 4.0mm diameter galvanised nails into timber.
| Specification | Value |
| Thickness | 2.3mm |
| Width | 27mm |
| Length | 100mm increments from 100mm to 6000mm |
| Load bearing capacity | 4KN |
| Material | Galvanised Steel |
Product code |
Size to choose from menu |
Overall length (Girth) |
Bend at 100mm |
Length after the bend |
| Ldmh-0300-b100 | 300mm | 300mm | Bend at 100mm | 200mm |
| Ldmh-0400-b100 | 400mm | 400mm | Bend at 100mm | 300mm |
| Ldmh-0800-b100 | 800mm | 800mm | Bend at 100mm | 700mm |
| Ldmh-1000-b100 | 1000mm | 1000mm | Bend at 100mm | 900mm |
Other sizes/alterations are available on request
These straps are available in 100mm increments from 100mm to 6000mm in length
