V26 Traditional Double Triangle Wall Ties - Boxes of 10 and 250
V26 Traditional Double Triangle Wall Ties - Boxes of 10 and 250
- Sold in boxes of 10 and 250
- Type 2 & 3 wall ties
- Stainless Steel Grade 304
- *Sizes over 300mm are not tested
V26 Traditional Double Triangle Wall Tie - Type 2 & Type 3 | Available in Boxes of 10 or 250
The V26 Traditional Double Triangle Wall Tie is designed to securely tie together the inner and outer leaves of a cavity wall, allowing them to act as a single structural unit. Featuring a traditional double triangle design with an integrated multidrip feature, this wall tie helps prevent moisture from tracking across the cavity, protecting the wall structure and maintaining thermal performance.
Suitable for masonry to masonry applications, the V26 wall tie can be installed either way up for added on-site flexibility. It offers excellent corrosion resistance and long term durability, making it ideal for use in external wall construction.
Performance
-
Non-combustible as defined in National Building Regulations
-
Excellent corrosion resistance with a service life of not less than 60 years
-
Tested to BS EN 845-1 as Type B (acoustic/sound) and Type 2 & Type 3 (strength)
-
Meets dynamic stiffness requirements of <113 MN/m³, with a tested value of 12.5 MN/m³ in a 100mm cavity
-
Suitable for external walls at a standard density of 2.5 ties per square metre
Key Features
-
Traditional double triangle wall tie design
-
Integrated multidrip feature reduces the risk of moisture bridging the cavity
-
Suitable for masonry to masonry cavity wall construction
-
Can be installed either way up
-
Low dynamic stiffness for improved acoustic performance
Specifications
| Tie Length | To suite cavity | Type |
| 150mm | 0mm | 2 |
| 200mm | 50-75mm | 2 |
| 225mm | 76-100mm | 2 |
| 250mm | 101-125mm | 2 |
| 275mm | 126-150mm | 3 |
| 300mm | 151-175mm | 3 |
| 325mm* | N/A | N/A |
| 350mm* | N/A | N/A |
| 400mm* | N/A | N/A |
| 450mm* | N/A | N/A |
Types & Applications
-
150mm to 250mm (Type 2 wall ties)
Suitable for buildings up to 15m high on flat sites where the basic wind speed does not exceed 31 m/s and altitude is no more than 150m above sea level -
275mm and 300mm (Type 3 wall ties)
Suitable for flat sites where the basic wind speed does not exceed 27 m/s and altitude is no more than 150m above sea level
Specification
-
Available for specification as Type 2 or Type 3 wall ties on the NBS Source platform
-
Supplied in boxes of 10 or boxes of 250, depending on project requirements
