Stainless Steel Bed Joint Reinforcement Ladder 2.7m Lengths (Pack of 20)
Stainless Steel Bed Joint Reinforcement Ladder 2.7m Lengths (Pack of 20)
- This brick reinforcement ladder is designed to enhance structural stability by distributing loads evenly across masonry walls.
- It is embedded in the bed joint masonry, helping to reduce cracking and improve resistance to lateral movement.
- Ideal for use in brickwork and blockwork construction
Stainless Steel Bed Joint Reinforcement Ladder 2.7m Lengths (Pack of 20)
The Stainless Steel Bed Joint Reinforcement Ladder improves the stability of masonry walls by incorporating steel reinforcement into the bed joints. This reinforcement is particularly effective in reducing the risk of cracking in masonry panels caused by structural movement.
This type of reinforcement is often referred to as Brickspan or MSF Masonry Reinforcement Ladder and is widely used to add strength to walls and manage cracks. It is particularly useful in high-stress areas, such as below window openings, where additional support is often required.
Specifications:
Width (mm) |
Length (m) |
Diameter (mm) |
Wall Thickness (mm) |
Pack Quantity |
Material |
| 60mm | 2.7m | 3mm |
102mm (Brick) 100mm or 125mm (Blockwork) |
20 Lengths | Stainless Steel |
| 60mm | 2.7m | 4mm (Flat) |
102mm (Brick) 100mm or 125mm (Blockwork) |
20 Lengths | Stainless Steel |
| 60mm | 2.7m | 5mm (Flat) |
102mm (Brick) 100mm or 125mm (Blockwork) |
20 Lengths | Stainless Steel |
| 100mm | 2.7m | 3mm | 100mm or 125mm (Blockwork) | 20 Lengths | Stainless Steel |
| 100mm | 2.7m | 4mm (Flat) | 100mm or 125mm (Blockwork) | 20 Lengths | Stainless Steel |
| 100mm | 2.7m | 5mm (Flat) | 100mm or 125mm (Blockwork) | 20 Lengths | Stainless Steel |
Applications:
Our Stainless Steel Bed Joint Reinforcement Ladder is ideal for various construction applications, including residential housing, commercial buildings, and other masonry structures. It provides essential support, reduces the risk of cracking, and enhances the overall stability of walls.
For more information please see our bed joint reinforcement blog post
